| DN: |
02 |
| Size: |
01 |
| Inch: |
5/64 |
| Outer Ø [mm]: |
5,0 |
| Inner Ø [mm]: |
2,0 |
| bending radius [mm]: |
20 |
| Working pressure [bar]: |
630 |
| burst pressure [bar]: |
1900 |
| Safety factor: |
3:1 |
| Standard ferrule: |
MT-PF2-DN2 |
| Weight [kg]: |
0,013 |
| Vacuum [bar]: |
0,93bar; 700 mm Hg - 13,5 psi; 27,5 Inch Hg |
| Color cover: |
black |
| Color inner tube: |
white |
| Cover: |
Polyurethane, pin pricked |
| Inner tube: |
Polyester-elastomer |
| MSHA-Approval: |
no |
| Material: |
Polyamide-hose with aramid fiber |
| Media: |
hydraulic oil H, HL und HLP according to DIN 51 524, grease |
| Product title long: |
Fixed length and components for assembling |
| Product title short: |
MT-MS |
| Reinforcement: |
A network of aramid fiber (kevlar-fiber) |
| Temperature range [°C]: |
- 40 °C to + 100 °C hydraulic oil H, HL und HLP according to DIN 51 524 |
| application: |
Measuring hose |
| number of layers: |
1 |
