VC30MSOF22-12
Valcon® swage fitting DKOL MSOF

Product info

• Technical data

  DN:	19
  Size:	12
  Inch:	3/4"
  Thread + standard:	Sealing cone with O-ring according to DIN 3865 (suitable for cone 24 ° DIN 3901 and 3902), union nut light series
  d [mm]:	15,0
  Pipe E [mm]:	22
  T:	M30-2
  E [mm]:	36
  C [mm]:	29,0
  L [mm]:	68,5
  Connection name Indunorm:	MSOF
  Connection type:	DKM
  Construction form:	0°
  Material:	Free cutting steel
  Surface:	CrIII
  Type of fittings:	VC series
